Description
Technical Specifications
| Frequency | 865 MHz to 868 MHz or 902 MHz to 928 MHz |
| Protocol | EPC Global UHF Class 1 Gen 2 or ISO 18000-6C |
| FM Mode | FHSS or fixed frequency, set by the software |
| RF Output | 0 dBm to 30 dBm adjustable |
| Communication Interface | WIFi IEEE802.11b/g/n or 4G or Bluetooth 4.0 |
| Application | WAREHOUSE |
| Operating System | Android 6.0 |
| Power Supply | 4000 mAh chargeable Ii-polymer battery |
| Color | Grey, black |
| Materials | CNC aluminum, PC + PC (SABIC) |
| Read Distance | > 22.9 ft (7 m) |
| CPU | Quad-core Cortex-A17 or 1.8 GHz |
| GPU | ARM Mali-T764 or High-performance 3D engine |
| Touch Screen | 0.04 in (1.1 mm) thickness tempered glass or 10- dot touch or operable with gloves |
| Hot Swapping Battery | Pistol style hot swapping battery system |
| Power or Volume X 2 | 3 ALPS buttons or Operating force 2.5 N or Operating life 1000000 cycles |
| Scan Trigger X 2 | OMRON button or Operating force 1.27 N or Operating life 1000000 cycles |
| Peak Inventory Speed | > 500 tags per second |
| Power | 4000 mAh chargeable Ii-polymer battery |
| USB Interface | Micro USB or MOLEX connector or Operating life 10000 cycles |
| Wireless Communication | WIFi IEEE802.11b/g/n or 4G or Bluetooth 4.0 |
| Data Collections | 2D Data matrix or QR Code or PDF417 or US Planet or UK Postal, etc 1DUPC or EASymbol SE955N or Code128 or Code39 or Code93 or Code11 or lnterleaved 2 of 5 or Discrete 2 of 5 oe Chinese 2 of 5 or Codabar or MSI or RSS |
| Accessories | Battery or Desktop charger or Charger and Hanging Lace or Data cable |
| Safety Drop Height | 6.5 ft (1.2 m) |
| IP Rating | IP64 |
| Humidity | 5 % RH to 95 % RH (non-condensing) |
| Operating Temperature | -4 °F to 140 °F (-20 °C to 60 °C) |
| Storage Temperature | -22 °F to 158 °F (-30 °C to +70 °C) |
| Dimensions | Profile 6.2 in X 3.1 in X 5.0 in (160 mm X 80 mm X 129 mm) Grip 4.3 in X 1.4 in X 1.8 in (111 mm X 38 mm X 47 mm) |
| Weight | 9.1 oz (260 g) |
