Description
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | EPC global UHF Class 1 Gen 2 or ISO 18000-6C |
| Shell Material | Aluminum |
| Input Voltage | DC 12 V to 24 V |
| Standby Current | < 70 mA |
| Max Working Current | 800 mA +/- 5 % at DC 12 V Input (33 dBm Output power working current) |
| Output Power | 0 dBm to 33 dBm |
| Output Power Accuracy | +/- 1 dB |
| Output Flatness | +/- 0.25 dB |
| Receive Sensitivity | < -85 dBm |
| Reading Speed | 700 tags per second |
| RSSI | Support |
| Antenna Connection Protection | Support |
| Environment And Temperature Monitor | Support |
| Working Mode | Single Tag or Multi-tag mode |
| Communication Interface | RS232 or TCP or IP |
| GPIO | 2 channel input, 2 channel output |
| Max Bps | Default: 115200 bps (adjustable: 38400 or 460800) |
| Reading Distance | 3.28 ft to 98.42 ft (1 m to 30 m) |
| Operating Humidity | < 95% 77 °F (+ 25 °C) |
| Working Temperature | -22 °F to 158 °F (- 30 °C to +70 °C) |
| Storage Temperature | -40°F to 185 °F (- 40 °C to + 85 °C) |
| Size | 7.87 in x 8.03 in x1.18 in (200 mm x 204 mm x 30 mm) |
| Weight | 28.92 oz (820 g) |
