Description
Technical Specifications
| Material | ABS |
| Frequency | 840 MHz to 960 MHz |
| Protocol | EPC C1 GEN 2 & ISO18000 6C |
| Communication | Standard：RS-232, Ethernet (RJ45)Optional：WIFI, 4G, RS-485, WiegandCustomized：Bluetooth |
| Power Supply | DC 12 V |
| Antenna | 9 dBi linear polarization antenna |
| Read Distance | 0 ft to 26.2 ft (0 m to 8 m) |
| Working Mode | Passive |
| Multi-Tags Reading | ≥ 200 tags per s |
| IP Rating | IP65 |
| Support Area | China, Europe, North America, South Korea, Japan,Taiwan… |
| Output Power | +5 dBm to +25 dBm |
| Output Power Flatness | ±0.2 dBm |
| Receiving Sensitivity | -62 dBm |
| Radio Frequency Port Standing Wave | ≤ 1.5 |
| Interface Communication Rate | 115200 bps |
| Working Temperature Monitoring | Support |
| Dense Reader Mode DRM | Support |
| Antenna Connection Protection | Support |
| Beep | Support |
| RSSI | Support |
| SDK | Support |
| Working Temperature | -22 °F to 158 °F (-30 °C to +70 °C) |
| Working Humidity | 5 % RH to 95 % RH |
| Storage Temperature | -40 °F to 185 °F (-40 °C to +85 °C) |
| Size | 11.0 in x 11.0 in x 2.9 in (280 mm x 280 mm x 75 mm) |
