Description
Overview
Amuse Tech Solutions Long Range Parking Management System UHF RFID Reader is a high-performance UHF RFID integrated reader. It is designed with low power dissipation and high integrated RFID chip solution, which has features of long reading distance, high identification speed, multiple interfaces and ease installation. It can be widely used in logistics tracking, commodity inventory, cargo sorting, vehicle management, personnel management, asset management, medical systems, cold chain management, temperature monitoring, power monitoring, anti-counterfeiting systems and production process control and many other applications.
Technical Specifications
| Frequency | EU 840 Mhz to 868 MHz or US 902 Mhz to 928 MHz or customized (Fixed or FHSS) |
| Protocol | EPCglobal UHF Class 1 Gen 2 or ISO 18000-6C |
| Rssi Testing | Support |
| Rf Power | 30 dBm ± 1 dB (Max) |
| Step Power | 30 dBm ± 1 dB (Max) |
| Step Power | 1 dBm |
| Signal Width | <250 KHz |
| Antenna | Built-in 8 dBi circular polarized antenna |
| Reading Speed | 100 tags per s |
| Effective Distance | up to 65.6 ft (up to 20 m) |
| Interface | RS232, RS485, Weigand 26/34, Trigger and RJ45(TCP/IP, UDP, PoE) 4G, Bluetooth and WIFI are optional |
| Baud Rate | 115200 bps |
| Operating Voltage | +12.0V (+9 V to +24 V) |
| Operating Current | <600 mA per DC 12 V |
| Standby Current | <200 mA per DC 12 V |
| Operating Humidity | <95 % RH 77 °F (+25 °C) Non-condensing |
| Storage Temperature | -22 °F to 185 °F (-30 °C to +85°C) |
| Operating Temperature | -4 °F to 131 °F (-20 °C to +55 °C) |
| Dimension | 10.24 in x 10.24 in x 3.15 in (260 mm x 260 mm x 80 mm) |
| Weight | 3.31 lb (1.5 kg) |
