Description
Technical Specifications
| Working Frequency | 902 MHz to 928 MHz or 865 MHz to 868 MHz |
| Protocol | ISO18000-6C (EPC G2) |
| Software | Provide C #, VC development of routines |
| SDK | Provides SDK with programming samples |
| Communication Port | RS232, TCP or IP, WG (RS485, WIFI customized) |
| Power Smoothness | < 0.5 DB |
| RF Power Range | 0 dBm to 30 dBm, Adjustable by software |
| Input/Output | 1 road trigger input and 1 road relay output |
| RSSI | RSSI signal strength detection label |
| Power | DC 7.5 V to 12 V per 3 A |
| Reading Range | 9.84 ft to 19.69 ft (3 m to 6 m) (test with 9662 card) |
| Working Temperature | -49 °F to 167 °F (-45 °C to +95 °C) |
| Storage Temperature | -58 °F to 185 °F (30 °C to +65 °C) |
| Size | 8.66 in x 8.66 in x 1.97 in) (220 mm × 220 mm × 50 mm) |
| Weight | 11.02 lb (5 kg) |
