Description
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | EPC C1 G2 |
| Antenna Polarization | Circular Polarization |
| Antenna Gain | 9 dBi |
| Data Interface | RJ45 (Customizable: RS232, WG26) |
| IO Interface | Support 2 optocoupler input and 2 relay output |
| Power | DC 12 V per 5 A |
| Reading Distance | up to 65.61 ft (20 m) |
| Working Temperature | -22 °F to 158 °F ( -30℃ to 70℃) |
| Dimension | 8.66 in x 8.66 in x 2.55 in (220 mm × 220 mm × 65 mm) |
| Weight | 3.31 lb (1.5 kg) |
